The 1500w Metal Sheet Laser Cutting Machine Factories Laser Sheet Metal Cutting Machine Cost in Canada/CA/United States/USA finds extensive applications across a diverse range of industries. It is an invaluable tool in the manufacturing of billboards, where precise and efficient cutting is crucial for creating eye – catching advertising displays. In the advertising and signage sectors, it plays a pivotal role in producing high – quality signs, signage, metal letters, and LED letters, enabling businesses to make a strong visual impact.
1500w Metal Sheet Laser Cutting Machine Advantages
1. Dual Exchange Platforms:
The machine has double exchange platforms with automatic loading and unloading. This setup saves labor and boosts efficiency.
2. High – Rigidity Bed:
The high – rigidity machine bed goes through an exclusive high – temp CNC furnace annealing process. It ensures long – term machine tool stability.
3. High Conversion Efficiency:
The fiber laser has high electro – optical conversion efficiency, up to 30%. It greatly reduces power consumption and operating costs.
4. Autofocus Cutting Head:
The laser cutting head comes with an autofocus feature for accurate cuts.
5. Intelligent Smoke Exhaust:
The laser cutting head comes with an autofocus feature for accurate cuts.
1500w Metal Sheet Laser Cutting Machine Specifications
| Model | 1530EL | 1560EL | 2560EL |
| Working area | 1515*3030 | 1515*6050 | 2520*6050 |
| Worktable bearing capacity | 800kg | 1300kg | 2200kg |
| Positioning Accuracy | ±0.03mm | ||
| Repositioning accuracy | ±0.02mm | ||
| Max. exchange time | 25s | 35s | 40s |
| Max. acceleration | 1.2G | ||
| Laser power | 1-6kw | ||
| Laser | Multiple options | ||
| Machine bed | Sheet welded bed | ||
| Max Running Speed | 140m/min | ||
1500w Metal Sheet Laser Cutting Machine Samples
We provide free proofing service. Welcome to consult.
Components of 1500w Metal Sheet Laser Cutting Machine
Intelligent focusing laser head
1) Cooling: both the collimating lens and the focusing lens group are cooling accessories. Besides, the cooling airflow nozzle is added, which effectively protects the nozzle and the ceramics and prolongs the working time.
2) Chasing aperture: through the 35 mm aperture, the interference of stray light is effectively reduced.
3) Autofocus: without human interference, the focusing speed can reach 10m/min, and the repeatability is about 50 microns.
Thick-walled carbon steel plate welding bed
Adopting high-quality carbon plate steel welding bed, it is more stable and durable than normal tube welding bed. The high-strength machine tool adopts 600 ℃ stress relief annealing treatment, which has strong structural rigidity, small deformation, and low vibration to ensure cutting accuracy.
Aviation aluminum beam
1) It has the characteristics of corrosion resistance, light weight, and high rigidity, which ensures high-speed movement during laser processing.
2) It has perfect dynamic performance, such as anti-distortion, anti-overturning, anti-deformation, etc., ensuring higher cutting accuracy.
Weihong LS1500/LS3000 Laser Cutting Control System
Weihong laser cutting control system is a software for plane laser cutting. It supports AI, DXF, PLT and international standard G codes generated by Mater Cam, Type3, Wentai, etc.
Except common editing and typesetting functions, it has unique processing sequence browsing and powerful material database to load the specification directly. Besides, operators can control the system through wireless handheld box and Ethernet conveniently.
DXTECH Services
We warmly welcome domestic and overseas customers to visit our factories and offices and talk about business in person. We now have one workshop with an area of 45,000㎡ in Jinan and one factory with an area of 30,000㎡ under construction in Taian, Shandong Province.
Your salesperson and factory technicians will together take care of all your after-sales issues from the moment you received the laser machine.
We provide free online training and techinical support. Besides, we can also go to your place to settle down the installation, debugging, training, and using matters.
DXTECH Quality Assurance
2 Years free warranty
- This warranty only covers normal use of the laser machine
- This warranty does not cover any third party software or virus related issues not purchased from DXTECH
- We continue to provide lifetime free technical support to original customers. However, the warranty is not transferable.
Complete After-sales Service
- Your salesperson and factory technicians will together take care of all your after-sales issues from the moment you received the laser machine.
- We provide free online training and techinical support. Besides, we can also go to your place to settle down the installation, debugging, training, and using matters.
