Advantages
- The 6000w large format fiber laser cutting machine for stainless steel cutting has an automatic lubrication system that covers up to 11 points, ensuring stability and preventing malfunctions with low oil alarms and replenishment functions that can extend machine life by up to 20%.
- In addition, the machine is environmentally friendly, with a first-of-its-kind oil-receiving system for the rails and frame that promotes environmental protection.
- High Rigidity and Durability: The machine bed is made from a stress-relieved annealed, highly rigid welded frame that ensures maximum strength and resilience to support loads of up to 1,000KG and maintain firm stability in a variety of applications.
- The 6000w large format fiber laser cutting machine for stainless steel cutting is equipped with rails and racks with an oil-recovery function for improved environmental friendliness, providing customers with outstanding environmental features.
Video
Applications
The 6000w large format fiber laser cutting machine for stainless steel cutting is capable of handling a diverse array of metal sheets, including stainless steel, carbon steel, galvanized steel, and highly-reflective materials such as aluminum and copper. This machine finds extensive application in fields like construction, metal sheet processing, decoration, automotive, aerospace, equipment manufacturing, advertising, crafts, and more.
Technical Parameters
| Model | DXTECH – 2560FP |
| Worktable size | 2530x6080mm |
| Table bearing capacity | 3050KG |
| Max. acceleration | 1.5G |
| Max. linkage speed | 140m/min |
| Positioning accuracy | 0.03mm |
| Repositioning accuracy | 0.02mm |
| Laser power | 6000W (Optional) |
| Voltage | 380V, 50HZ, 3P |
Components of Fiber Laser Cutting machine
Intelligent focusing laser head
1) Cooling: both the collimating lens and the focusing lens group are cooling accessories. Besides, the cooling airflow nozzle is added, which effectively protects the nozzle and the ceramics and prolongs the working time.
2) Chasing aperture: through the 35 mm aperture, the interference of stray light is effectively reduced.
3) Autofocus: without human interference, the focusing speed can reach 10m/min, and the repeatability is about 50 microns.
Thick-walled carbon steel plate welding bed
Adopting high-quality carbon plate steel welding bed, it is more stable and durable than normal tube welding bed. The high-strength machine tool adopts 600 ℃ stress relief annealing treatment, which has strong structural rigidity, small deformation, and low vibration to ensure cutting accuracy.
Aviation aluminum beam
1) It has the characteristics of corrosion resistance, light weight, and high rigidity, which ensures high-speed movement during laser processing.
2) It has perfect dynamic performance, such as anti-distortion, anti-overturning, anti-deformation, etc., ensuring higher cutting accuracy.
FSCUT2000C Laser Cutting Control System
- More rational arrangement of parts, reducing plate waste
- Quickly cut off the plate to recycle the residual material
- Automatic edge searching: various edge searching methods, accurate and fast to determine the angle of plate searching.
- Flying cutting: reduce acceleration, deceleration and lifting in the cutting process to increase cutting speed.
The Past Work
FAQ
stainless steel, carbon steel, alloy steel, silicon steel, spring steel, aluminum, aluminum alloy, galvanized sheet, pickled plate, copper, silver, gold, titanium and other metal plates and pipes.
Fiber laser, stepper motor, servo motor, bed, laser head, water chiller, control system, etc.
Protective lenses, nozzles, ceramic rings.
The shape of the laser beam, the width of the slit, the accuracy of the table, and the material of the work piece.
