Application
Square pipe laser cutting machine process various metal tubes—round, square, and profiled—with high precision and efficiency. Capable of hole cutting, chamfering, grooving, vertical cutting, and tube engraving, the machines excel in diverse applications: automotive exhaust pipes, water/oil pipelines, fitness equipment, medical beds, bicycle/e-bike frames, strollers, kitchen storage racks, and cookware.
Video
Advantages
1. Universal Tube Compatibility
Processes standard tubes (round, square, rectangular) and most profiled materials: hexagonal tubes, oval tubes, channels, angles, and open-section profiles.
2. Intelligent Nesting System
Equipped with Fangling bus CNC system for multi-type tube nesting. Supports common-edge island cutting to boost material utilization by 15-20%. Built-in nesting software reduces customer costs.
3. Semi-Auto Loading Capacity
Standard semi-automatic loader handles tubes 6000-6500mm in length, with a 10-tube storage capacity.
4. Pneumatic Chuck Efficiency
Compact axial design of pneumatic chuck achieves zero tailstock material waste, lowering costs. Four-jaw auto-centering clamping with 130mm square chuck expands clamping range.
DXTECH Service
We warmly welcome domestic and overseas customers to visit our factories and offices and talk about business in person. We now have one workshop with an area of 45,000㎡ in Jinan and one factory with an area of 30,000㎡ under construction in Taian, Shandong Province.
Your salesperson and factory technicians will together take care of all your after-sales issues from the moment you received the laser machine.
We provide free online training and techinical support. Besides, we can also go to your place to settle down the installation, debugging, training, and using matters.
Components of Metal Tube Fiber Laser Cutter
Intelligent focusing laser head
1) Cooling: both the collimating lens and the focusing lens group are cooling accessories. Besides, the cooling airflow nozzle is added, which effectively protects the nozzle and the ceramics and prolongs the working time.
2) Chasing aperture: through the 35 mm aperture, the interference of stray light is effectively reduced.
3) Autofocus: without human interference, the focusing speed can reach 10m/min, and the repeatability is about 50 microns.
TubePro tube cutting software
1) It is a professional tube cutting system, which can realize automatic centering and eccentric compensation of metal pipes to ensure cutting accuracy.
2) Common edge cutting: it can reduce the residual material and save the production cost.
3) Corner cutting process: the corners are not burnt, and the section quality is good.
MFSC 3000C Laser
1) Laser standard with Max laser, optional Raycus/IPG
2) Configurable laser power range 1500W, 2000W, 3000W
Feedback from Customers All Over The World
We provide free proofing service. Welcome to consult.
FAQ
stainless steel, carbon steel, alloy steel, silicon steel, spring steel, aluminum, aluminum alloy, galvanized sheet, pickled plate, copper, silver, gold, titanium and other metal plates and pipes.
Fiber laser, stepper motor, servo motor, bed, laser head, water chiller, control system, etc.
Protective lenses, nozzles, ceramic rings.
The shape of the laser beam, the width of the slit, the accuracy of the table, and the material of the work piece.
