Advantages
- Exceptional Stability from Carbon Steel Build
Constructed with carbon steel, this high – precision fiber laser cutting machine benefits from the material’s toughness and ductility. The application of stress relief annealing and vibration aging during welding and processing ensures long – term durability, promising no deformation for two decades. - Swift and Precise with Cast Aluminum Beam
The cast aluminum beam, post artificial aging and solution treatment, offers remarkable integrity. Its lightweight design combined with high rigidity enables high – speed movement and accurate cutting of intricate patterns. - Stable Processing on Marble Tabletop
The marble tabletop, with its high precision, low linear expansion coefficient, and rust – resistant nature, is easy to maintain. Its acid and alkali resistance, along with high hardness and wear – resistance, bolsters the machine’s stability and accuracy. - Safety – Compliant and Clean Operation
The fully enclosed laser protective glass cover, meeting European CE standards, filters internal smoke from laser cutting. This ensures a safe working environment while controlling pollution. - Flexible Mobility for Efficient Work
Equipped with a mobile platform, the machine allows for flexible processing. It simplifies material handling, enhancing overall operational efficiency.
DXTECH Service
We warmly welcome domestic and overseas customers to visit our factories and offices and talk about business in person. We now have one workshop with an area of 45,000㎡ in Jinan and one factory with an area of 30,000㎡ under construction in Taian, Shandong Province.
Your salesperson and factory technicians will together take care of all your after-sales issues from the moment you received the laser machine.
We provide free online training and techinical support. Besides, we can also go to your place to settle down the installation, debugging, training, and using matters.
Technical Parameters
| Model | DXTECH – Q9090 |
| Working area | 905*905mm |
| Worktable bearing capacity | 140kg KG |
| Positioning Accuracy | ±0.03mm |
| Repositioning accuracy | ±0.02mm |
| Max. acceleration | 1.2G |
| Laser power | 1-3kw |
| Laser | Raycus, MAX |
| Max. linkage speed | 140m/min |
Components of High Precision Fiber Laser Cutting Machine
Intelligent focusing laser head
1) Cooling: both the collimating lens and the focusing lens group are cooling accessories. Besides, the cooling airflow nozzle is added, which effectively protects the nozzle and the ceramics and prolongs the working time.
2) Chasing aperture: through the 35 mm aperture, the interference of stray light is effectively reduced.
3) Autofocus: without human interference, the focusing speed can reach 10m/min, and the repeatability is about 50 microns.
Thick-walled carbon steel plate welding bed
Adopting high-quality carbon plate steel welding bed, it is more stable and durable than normal tube welding bed. The high-strength machine tool adopts 600 ℃ stress relief annealing treatment, which has strong structural rigidity, small deformation, and low vibration to ensure cutting accuracy.
Aviation aluminum beam
1) It has the characteristics of corrosion resistance, light weight, and high rigidity, which ensures high-speed movement during laser processing.
2) It has perfect dynamic performance, such as anti-distortion, anti-overturning, anti-deformation, etc., ensuring higher cutting accuracy.
We provide free proofing service. Welcome to consult.
FAQ
stainless steel, carbon steel, alloy steel, silicon steel, spring steel, aluminum, aluminum alloy, galvanized sheet, pickled plate, copper, silver, gold, titanium and other metal plates and pipes.
Fiber laser, stepper motor, servo motor, bed, laser head, water chiller, control system, etc.
Protective lenses, nozzles, ceramic rings.
The shape of the laser beam, the width of the slit, the accuracy of the table, and the material of the work piece.
