3000W Auto Feeding Laser Cutting Machine Applications
Unwinding and leveling machines are widely used in modern manufacturing. For example: in the field of automobile manufacturing, it is used to deal with all kinds of automobile parts and components required for the production of metal plates, such as, body shell of the large steel plate, engine, transmission and other internal components used in the thin steel plate and so on. Electrical equipment production industry, such as refrigerators, air conditioners, washing machines and other home appliances manufacturing, open coil leveling machine for the manufacture of shell, liner and internal structural parts of the metal plate processing.
High Performence 3000W Auto Feeding Laser Cutting Machine Advantages
1. Intelligent Software for Swift Production Adaptability
The laser cutter is equipped with intelligent sampling software and a control system. This enables rapid conversion of product specifications and shapes. As a result, it is highly suitable for various batch production scenarios, allowing manufacturers to efficiently switch between different product runs.
2. High – Performance Fiber Laser for Fast Cutting
Featuring a high – quality fiber laser cutter, this machine offers reliable performance. Notably, its laser cutting speed is impressively fast. For instance, when cutting 1mm – thick stainless steel, the cutting speed can reach up to 45 meters per minute, ensuring high – efficiency production.
3.Cost – and Energy – Saving with No – Mold Requirement
One of its major advantages is that it doesn’t need molds for stamping. This significantly cuts down on mold manufacturing and maintenance costs. Additionally, since the equipment doesn’t rely on large presses, production energy consumption is greatly reduced. Moreover, it also helps in reducing environmental noise pollution.
4. Material – Efficient Continuous Production
The machine enables continuous production using rolled material. This eliminates the material loss that typically occurs at the start and end of single – piece production, optimizing material usage and reducing waste.
High Performence 3000W Auto Feeding Laser Cutting Machine Specifications
| Model | DXTECH-1530FC | DXTECH-1540FC | DXTECH-2040FC |
| Working area (mm) | 1515*3030 | 1515*4040 | 2020*4040 |
| Max. acceleration | 1.5G | 1.5G | 1.5G |
| Worktable | Rolling blade | Rolling blade | Rolling blade |
| Positioning accuracy | ±0.05mm | ±0.05mm | ±0.05mm |
| Repositioning accuracy | ±0.03mm | ±0.03mm | ±0.03mm |
| Laser power | 1kW – 2kW | 1kW – 2kW | 1kW – 2kW |
| Coil sheet thickness | 0.5-3mm | 0.5-3mm | 0.5-3mm |
| Machine bed | Plate welded bed | Plate welded bed | Plate welded bed |
| Laser | Multiple options | Multiple options | Multiple options |
| Focusing method | Auto/manual | Auto/manual | Auto/manual |
| X/Y-axis max. linkage speed | 140m/min | 140m/min | 140m/min |
| Leveling speed | ≤20m/min | ≤20m/min | ≤20m/min |
| Coil weight | ≤15t | ≤15t | ≤15t |
DXTECH Services
We warmly welcome domestic and overseas customers to visit our factories and offices and talk about business in person. We now have one workshop with an area of 45,000㎡ in Jinan and one factory with an area of 30,000㎡ under construction in Taian, Shandong Province.
Your salesperson and factory technicians will together take care of all your after-sales issues from the moment you received the laser machine.
We provide free online training and techinical support. Besides, we can also go to your place to settle down the installation, debugging, training, and using matters.
DXTECH Quality Assurance
2 Years free warranty
- This warranty only covers normal use of the laser machine
- This warranty does not cover any third party software or virus related issues not purchased from DXTECH
- We continue to provide lifetime free technical support to original customers. However, the warranty is not transferable.
Complete After-sales Service
- Your salesperson and factory technicians will together take care of all your after-sales issues from the moment you received the laser machine.
- We provide free online training and techinical support. Besides, we can also go to your place to settle down the installation, debugging, training, and using matters.
Customer feedback
High Performence 3000W Auto Feeding Laser Cutting Machine Samples
We provide free proofing service. Welcome to consult.
Laser Machine Upgrade
DXTECH is committed to providing one-stop processing solutions for your metal processing factory. We not only provide a complete production line of fiber laser cutting machine + CNC press brake + handheld laser welding machine, but also provide a series of auxiliary equipment, such as Hydraulic shearing machine, Channel letter bender, Metal roll forming machine and Laser rust remover, etc.
- One-stop processing
- More efficient production
Choosing DXTECH means you no longer have to worry about finding manufacturers of various machines and equipment. Our comprehensive services will ensure that your production process is efficient and smooth.
DXTECH focuses on providing customized equipment upgrade solutions for your metal processing plant. If your factory is still using traditional equipment such as plasma cutting machines, hydraulic shearing machines or water jet cutting machines that have low processing efficiency and unsatisfactory cutting quality, then DXTECH will be your ideal choice.
- More efficient
- More precise
- More energy-saving
We can help you upgrade these equipment to more efficient, more precise, and more energy-saving fiber laser cutting machines, thereby greatly improving processing efficiency and cutting quality, and bringing a qualitative leap to your factory.
